| Attribute Name |
Value |
| Battery Type |
Lithium Iron Phosphate (LiFePO₄), 6,000+ cycles |
| Battery Capacity |
100kWh (modular/expandable) |
| AC Output |
10kW continuous, pure sine, three-phase, 380/400/415V, 50/60Hz |
| PV Input |
Multi-MPPT, up to 50kW+ (site dependent) |
| Communication |
RS485, CAN, Wi-Fi/Ethernet (remote monitoring) |
| Protection Features |
Overload, short-circuit, OVP/UVP, overheat, surge, anti-islanding |
| Installation Enclosure |
IP54+ industrial container |
| Operating Temp |
Charge: 0–50°C; Discharge: -15–55°C |
| Certifications |
Australian Made®, CE, ROHS, FC, TUV, UN38.3, IEC |
| Dimensions (WxDxH mm) |
~1,800×2,400×1,200 |
| Weight |
~1,000kg+ |
