Additional information
| Dimensions | 620 × 368.5 × 365 cm |
|---|
Battery Type: LiFePO₄, >6,000 cycles (to 80% capacity), stackable (up to 8, up to 40.96kWh)
Battery Capacity per Kit: 5.12kWh (51.2V), usable ~4.6kWh
Batteries per System: up to 8 (max 40.96kWh)
Depth of Discharge: 90–95%
AC Output:
10kW: 10,000W continuous, 30,000W peak (300%), 220/230/240V, 50/60Hz, 22.7A/phase
15kW: 15,000W continuous, 30,000W peak, 380/400/415V, 50/60Hz, 22.7A/phase
Output Waveform: Pure Sine Wave
Surge Capability: Up to 150% rated power (see model)
PV (Solar) Input:
10kW: up to 18,000W solar input, MPPT range 120–430Vdc, max PV voltage 450Vdc, max DC input current 18A × 3
15kW: up to 18,000W solar input, MPPT range 120–430Vdc, max PV voltage 450Vdc, max DC input current 18A × 3
Transfer (UPS) Time: ≤20ms
Input/Output Connection: 3-phase
Protection: Fire suppression, overload, undervoltage, overvoltage, overheating, short circuit, anti-reverse, surge
Enclosure: IP20 (indoor), fan cooling
Operating Temperature: Charge: 0–50°C, Discharge: -10–55°C, Storage: -15–60°C
Noise: <25dBA (battery)
Communication: Wi-Fi (optional), RS232/CAN2.0
Certifications: Australian Made®, CE, UN38.3, TUV, ROHS
| Dimensions | 620 × 368.5 × 365 cm |
|---|
| Attribute Name | Value |
| Battery Type | LiFePO₄, >6,000 cycles, stackable |
| Battery Capacity | 5.12kWh per kit, up to 40.96kWh (8 modules) |
| Depth of Discharge | 90–95% |
| AC Output | 10,000W / 15,000W continuous, 30,000W peak, pure sine wave, 3-phase, 220–415V, 50/60Hz |
| PV Input | up to 18,000W, 120–430Vdc, MPPT, max 450Vdc, 18A × 3 |
| Max. PV Input Voltage | 450Vdc |
| Communication | RS232, CAN2.0, Wi-Fi (optional) |
| Transfer Time | ≤20ms |
| Cooling | Fan (main), natural convection (battery) |
| Operating Temp | Charge: 0–50°C, Discharge: -10–55°C, Storage: -15–60°C |
| Protection Features | Fire suppression, overload, undervoltage, overvoltage, overheat, short circuit, surge |
| Certifications | Australian Made®, CE, UN38.3, TUV, ROHS |
| Weight (main/battery) | 49.4kg (main), 46.7kg (battery) per unit |
| Dimensions (WxHxD mm) | 620×368.5×365 (main), 620×139×365 (battery) |
| Stackable Expansion | Up to 8 batteries (40.96kWh total) |
| Noise | <25dBA (battery) |
